PINARELLO F9

Description

PINARELLO F9: BORN TO RACE, NO DISCUSSION

Our history is one of extraordinary victories, iconic bicycles, passion, and expertise. The new Pinarello F9 was born with this unique DNA, created to offer extremely high performance and guide you straight to victory. All true riders know that what goes up, must go down. For this reason, the Pinarello F is designed to excel on all terrain and is as adept at climbing as it is comfortable on a high-speed descent. This is what we mean by ALL-ROUND PERFORMANCE.

INNOVATION PINARELLO F9

CARBON T900 3K
ONDA FORK
COMPETITION GEOMETRY
ASYMMETRIC FRAME PINARELLO F



CARBON T 900 3K

The right balance between reactivity, dampening capabilities and lightness for competition.

ASYMMETRIC FRAME PINARELLO F

For first Pinarello understood that, while the thrust applied to both pedals is the same, the pull on the chain applies to the right side only. For this reason, all frames are optimized to compensate these unbalanced forces.

ONDA FORK

A distinctive Pinarello Technology since 2000. The shape of the fork delivers precise turning abilities, stability and reduction of longitudinal and lateral shocks.



COMPETITION GEOMETRY PINARELLO F9

30 grand tours have been won on Pinarello bikes. 70 years of victories and continuous improvements have been distilled into what we consider the best race geometry in the industry.



CE	CC	L	A [°]	B [°]	P	T	D	R	G	REACH	STACK
425	430	500	74.4	69.5	406	97	67	43	373	351.3	502.5
450	465	515	74.4	70.5	406	104	72	43	373	365.2	517.7
465	500	525	74	71.4	408	109	72	43	373	372.1	525.5
485	515	535	73.7	72	408	114	72	43	373	378.1	532.3
500	530	545	73.7	72.5	408	123	72	43	373	385.6	542.6
515	545	555	73.4	72.8	410	138	72	43	373	388.3	557.9
525	560	565	73	73.2	410	149.5	72	43	373	390.8	570.3
560	575	578	73	73.7	410	178	72	43	373	395.4	599.3
580	595	600	72.4	73.4	410	220	67	43	373	400.3	633.5



CE: SEAT TUBE CENTER – END, CC: SEAT TUBE CENTER – CENTER, L: TOP TUBE CENTER – CENTER, A[°]: SEAT TUBE ANGLE, B[°]: HEADTUBE ANGLE, P: CHAINSTAY, T: HEADTUBE, D: BB DROP, R: FORK RAKE , G: FORK HEIGHT, REACH, STACK





ALL COMPONENTS DURA ACE DI2 VERSION:

FRAME SET

FRAME

TorayCa T900 UD, TiCR™ cable routing, Italian BB, UCI approved

FORK

F Onda Fork with ForkFlap™, 1.5′ upper and lower steerer, Ultra Light Headset bearings

DRIVETRAIN

CRANKSET AND CHAINRINGS

Shimano Dura Ace Di2 FD-R9200 12s

FRONT DERAILLEUR

Shimano Dura Ace Di2 FD-9200 11S

CASSETTE

Shimano Dura Ace CS-R9200 12S

CHAIN

Shimano Dura Ace CN-HG 12S

BOTTOM BRACKET

Shimano Dura Ace SM-BB9200

BRAKES

FRONT BRAKE DISC

Dura Ace BR-R9200, 2 pistons caliper, 160mm rotor

REAR BRAKE DISC

Dura Ace BR-R9200, 2 pistons caliper, 140mm rotor

COCKPIT

INTEGRATED HANDLEBAR

MOST Talon Ultra Light

BAR TAPE

most bar tape

SEATPOST

fsc frontal seat clamp

WHEELS AND TIRES

WHEELSET DISC

MOST Ultrafast 40*

AXLES DISC

Ultra Light Custom Axle 12×100 & 12×142, tool free removal

ACCESSORIES AND NOTES

BOTTLES AND BOTTLE CAGES

Bottlecage Trap PACF ø 74mm, Fly Bottle Pinarello Bottle 550ml Black



ALL COMPONENTS SRAM RED AXS VERSION:

FRAME SET

FRAME

TorayCa T900 UD, TiCR™ cable routing, Italian BB, UCI approved

DRIVETRAIN

CRANKSET AND CHAINRINGS

SRAM Red AXS

FRONT DERAILLEUR

SRAM Red AXS

CASSETTE

Sram Red XG-1290

CHAIN

SRAM Red AXS

BOTTOM BRACKET

SRAM Red AXS

BRAKES

FRONT BRAKE DISC

SRAM Red 12S 2 pistons caliper, 160mm rotor

REAR BRAKE DISC

SRAM Red 12S 2 pistons caliper, 160mm rotor

COCKPIT

INTEGRATED HANDLEBAR

MOST Talon Ultra Light

BAR TAPE

Bar Tape MOST Ultragrip evo 3mm – Black

SEATPOST

Pinarello Aero seatpost with 3D printed titanium top seatclamp and bolts

SEAT CLAMP

fsc frontal seat clamp

WHEELS AND TIRES

WHEELSET DISC

MOST Ultrafast 40*

AXLES DISC

Ultra Light Custom Axle 12×100 & 12×142, tool free removal

ACCESSORIES AND NOTES

BOTTLES AND BOTTLE CAGES

Bottlecage Trap PACF ø 74mm, Fly Bottle Pinarello Bottle 550ml Black





Bike available at l’Officina in Pernes les Fontaines, closed to the Luberon and the Mont Ventoux. Do not hesitate to contact us or visit us, our passionate team will be glad to help you.
